Pellicon
®
Single Pass TFF Accessories Installation and User Guide 9
Pellicon
®
2 Cassette Installation
Required Equipment
Items listed in this table are required for a three-section single-
pass TFF installation with Pellicon
®
2 Cassettes. Sections may be
added or removed as needed for each specific application.
Item Description Quantity
Pellicon
®
Single-Pass TFF Cassette diverter plate 3
Pellicon
®
Single-Pass TFF Cassette retentate
collection plate
1
Pellicon
®
2 Cassette (includes two silicone gaskets) 3
Pellicon
®
2 gasket (spare) 1
Pellicon
®
stainless steel holder 1
NOTES
Refer to the Pellicon
®
2 Cassette Installation Guide for cassette
installation instructions.
Install only identical cassettes in the filter holder. Do not mix
cassettes with different screens, membrane types, filtration
areas, or nominal molecular weight cutoffs.
Installation of Pellicon
®
2 Cassettes requires inter-cassette
gaskets. Each cassette is provided with two gaskets.
Installation with diverter plates requires one additional
gasket, which must be ordered separately.
The Pellicon
®
Single-Pass TFF Cassette retentate collection
plate is required to collect the retentate from the single-
pass TFF cassette installation.
The diverter plates must be installed between individual
cassettes with the tab locations alternating as shown in the
following illustration.
