Millipore Pellicon Single Pass TFF - Pellicon 3 88 CM; Cassette Installation

12 www.sigma-aldrich.com
Pellicon
®
3 88 cm
2
or 0.11 m
2
Cassette
Installation
Required Equipment
Items listed in this table are required for a three-section single-
pass TFF installation with Pellicon
®
3 88 cm
2
or 0.11 m
2
Cassettes.
Sections may be added or removed as needed for each specific
application.
Item Description Quantity
Pellicon
®
Single-Pass TFF Mini Kit (includes four
diverter plates and two silicone gaskets)
1
Pellicon
®
3 88 cm
2
and 0.11 m
2
Cassette 3
Pellicon
®
Mini holder with extended tie rods 1
NOTES
Refer to the Pellicon
®
3 Cassette Installation Guide for cassette
installation instructions.
Install only identical cassettes in the filter holder. Do not mix
cassettes with different screens, membrane types, filtration
areas, or nominal molecular weight cutoffs.
The diverter plates must be installed between individual
cassettes with the ports in alternating positions as shown in
the following illustration.
