Chapter 2 - Specification
Basic Machine Specifications
Machine Model RW15 RH20 RH30
Maximum Table Load
750 lb
340 kg
2500 lb
1130 kg
3000 lb
1360 kg
Machine Weight
6500 lb
2950 kg
8000 lb
3628 kg
11,000 lb
5000 kg
Maximum Tool Diameter / Length /
Weight
4" / 11" / 10 lb
100mm / 280 mm /
4.5kg
3.5" / 11" / 15 lb
80mm / 280mm /
7 kg
3.5" / 11" / 15 lb
80mm / 280mm /
7 kg
16 Pocket Carousel ATC 40 Taper Standard Optional Optional
24 Pocket Carousel ATC 40 Taper N/A Optional Optional
Standard Current/Voltage Requirements
208-240 VAC
60 Amps 60 Amps 60 Amps
Transformer 23 KVA 23 KVA 23 KVA
Coolant Capacities
Gallons 50 7.5 15
Liters 190 13 25
Coolant Recommendation
Consult with a reputable coolant supplier in your area. You should use non-toxic, non-
corrosive, and non-flammable coolant. Avoid chlorine and sulfur, which may harm the
paint finish.
Control Instructions, Schematics, Complete Specification Sheets
• Detailed instructions for programming the machine and operating it from the front
panel are given in the CNC operation manual provided separately.
• Electrical schematics, pneumatic diagrams (if applicable) and hydraulic diagrams
(if applicable) are located in the electrical and mechanical manual.
