Nominal Motor
Power @ 50%
actuator load
20W 13.5W
Electrical
equipment
dissipated power
(ACC-10T
including motor @
85 Vac 50Hz and
100% load)
33 VA
Starting currents
AC: Is= 2 A (starting current)
DC: Is= 6 A (starting current)
Technical specifications ACC - ¾ turn ACC - 10 turns
MECHANICAL
SPECIFICATIONS
Gear design
The Actuator is mechanically self-locking and
lubricated for product lifetime
Manual
emergency
operation
Manual emergency operation via a 10mm hexagonal
manual shaft
Output flange The Actuator flanges comply with ISO 5211 F07
Lubrication
The actuators are lubricated for the product lifetime
and do not require any special service
ELECTRICAL SPECIFICATIONS
Power supply
The actuators can operate on a wide variety of single
phase power supply
From 85VAC to 260VAC 50/60Hz and 24VDC (12VDC
single power supply available on request)
Terminal
compartment
Push-in type terminals for controls and power supply
Internal and external earth grounding post.
Power Terminals wire section acceptance:
- From 24 to 14 AWG / 0.25 to 2.5mm²
Signal Terminals wire section acceptance:
-
From 24 to 16 AWG
/ 0.25 to 1.5mm²
Conduit entries 2 x ¾ NPT as standard (cable glands are not supplied)
