44
44
4
Instruction Manual MA871 Refractometer for Sucrose Measurements
H. BATTERY COVER
I. BATTERY COMPARTMENT
BOTTOMBOTTOM
BOTTOMBOTTOM
BOTTOM
A. LIQUID CRYSTAL DISPLAY (LCD)
B. READ KEY (USER MEASUREMENT)
C. ZERO KEY (USER CALIBRATION)
D. ON/OFF
E. PRIMARY DISPLAY
F. SECONDARY DISPLAY
G. STAINLESS STEEL SAMPLE WELL AND PRISM
FRONT PANELFRONT PANEL
FRONT PANELFRONT PANEL
FRONT PANEL
