Maintenance Manual > Operation Flow > Cut Mode > SETUP
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.2
Rev.
8.3.2 SETUP
FUNCTION C
SETUP <ENT>
[FUNCTION],
[] / []
:CUT2
:CUT3
:PEN
:HALF
ENDS :HIGH [H_____H]
INNER:OFF No.6to1
ENDS :HIGH [H_____H]
INNER:OFF No.6to1
SETUP
SELECT :CUT1
[CUT1]
PINCH ROLLER <ent>
[FUNCTION]: To the next screen [FUNCTION]: To the previous screen
[FUNCTION],
[] / []
[CUT1]MARK DETECT
DETECT :OFF
[CUT1]MARK DETECT
DIST.REVI. :OFF
[CUT1]
MARK DETECT <ent>
:1pt
:2pt X
:2pt Y
:3pt
:4pt
[CUT1]MARK DETECT
SIZE = 10mm
:4 to 40
[CUT1]MARK DETECT
OFFSET Y() = 0.0mm
[CUT1]MARK DETECT
OFFSET X() = 0.0mm
:-40.0 to 40.0 :-40.0 to 40.0
[CUT1]MARK DETECT
FORM :TYPE1
:TYPE2
[CUT1]MARK DETECT
COPIES Y()= 1
[CUT1]MARK DETECT
COPIES X()= 1
:0 to 9999 :0 to 9999
[ON]: To the next screen
[CUT1]CUT MODE
SETUP :STD.
[CUT1]
CUT MODE <ent>
:FAST
:FINE
[FUNCTION],
[] / []
[CUT1]AUTO CUT
SETUP :OFF
[CUT1]
AUTO CUT <ent>
:ON
[CUT1]AUTO CUT
CUT MARGIN = 30mm
:0 to 50
[ON]: To the next screen
[FUNCTION],
[] / []
[CUT1]MARK DETECT
SPEED LIMIT = 1cm/s
:0 to 60
[CUT1]MARK DETECT
SKEW CHECK = 0mm
:0 to 99
[CUT1]P/C ADJUST
P/C SCALE ADJ. <ent>
P/C SCALE ADJ.
CLEAR < > PRINT
P/C SCALE ADJ.
DIRECTION = +
P/C SCALE ADJ.
ADJ.VALUE = 5
[CUT1]P/C ADJUST
P/C ORIGIN OFS. <ent>
P/C ORIGIN OFS.
540dpi <ent>
P/C ORIGIN OFS.
PRINT START :ent
[FUNCTION],
[  ] / [  ]
P/C ORIGIN OFS.
Y = 0 X = 0
[CUT1]
P/C ADJUST <ent>
Adjust misalignment
Remove the printed &
cut pattern
:720dpi
:-
Check misalignment of
the pattern 0
Print all the pattern.
Cut the pattern 0.
[FUNCTION],
[] / []
Cut the pattern 1 to 9
Enter the fit pattern
