MIMAKI CJV30-100 Service Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
2.3.10 P.1
1
2
3
4
5
6
7
8
R.1.0
Maintenance Manual > Electrical Parts > Circuit Board Specifications > Head Memory PCB Assy
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
2.3.10 Head Memory PCB Assy
 Outline
Board name: Head Memory PCB Assy
Stores Head ID information. Is provided together with the head(s), and does not operate independently.
 List of connectors
CN No Pin Connected to: Remarks
CN1 3 Head Heating Thermistor Not used.
CN2 11 Ink Slider PCB Assy
CN3 2 Head Heating Heater Not used.
CN4 2 Head Heating Heater Not used.
CN2
CN4
CN3
CN1
