1. Summarize
Minco 820B genset controller adopts high performance microprocessor and industry components. It
has measuring, controlling, protection, four remote control, flexible software setting functions and high
anti-jamming ability. Can display all the measuring parameters, control parameters and genset running
state. Actually meets different types of generator auto control requirements . When the mains supply is
failure, the control system will automaticly give a start signal to start the genset and resume the power
supply in short time; After the mains supply is normal, the control system will unload and shut down
automaticly. Adding the monitoring function of mains supply electric quantity, applies to mains supply
and genset supply automatic transfer power supply system.
2. Characteristic
1. Double processing chip, real virtual value measuring, action smartly;
2. Mains and genset double power manager, Automatic Transfer Switch system;
3. Wide-screen LCD display with back-light;
4. Chinese and English double language menu, mutual operation, can be set and operated individually;
5. Auto start, Auto protection, ATS control;
6. Perfect auto protection, warning details and working statement character display directly, fault record
more than 50 items;
7. Double coolant temp., double oil pressure, fuel level and oil temp. etc connected parameters and so
on;
8. All relay contact capability is above 10A/250VAC/30VDC;
9. Electronic speed adjustment and mechanical speed adjustment control compatible, timing start or
stop and etc. custom setting; -
10. RS232 communication, attached “four remote control” monitor software;
3. Fixup dimension drawing
4. Function define and operate instruction
4.1．Operate panel function instruction
Operate panel is composed of 128X64 LCD display ,operation keys and state indicator light and
system menu operate press keys.
Operate panel W 213 X H 153mm
Install hole W 199 X H 139mm
Deepth D 52mm
