- 4 -
29 Idle NO (normal open) Battery positive
30 Not connected DC speed adjust motor negative pole
31 Idle common DC speed adjust motor positive pole
32 Pre-fuel
33 Common port 2(Pre-fuel and fault common contact port)
34 Fault
35 Fuel (stop when ETS)
36 Common port 1(Fuel and Crank common contact port)
37 Crank
Switch input port（add photoelectricity insulation，valid when connect to GND）
Electronic governor Mechanical speed control
38 Not connected DECelerate limited
39 Not connected ACCelerate limited
40 High oil temp./low fuel level
41 Low oil pressure
42 High coolant temp.
43 Remote reset
44 Remote start
45 Emergency stop
46
47
Rotate speed signal input
GND, inside connect with battery cathode
5. Parameter setting
All parameters can be read and write through communication port, details see communication
protocol. Except coolant temp., oil press., oil temp./ fuel level sensor option input sensor curve data adjust,
all the parameters can be setting by the controller.
Press ENT
Enter to parameter setting interface
Switch Inputs status Alarm limit set
Relay Outputs status Measure regulate
Shutdown Record Delay time set
Date and time set System set
Press＋or－
Select the examine /setting parameter content (reversed display when selected)
Press ENT
Enter to the selected menu
Press Exit
Exit the parameter setting state
Attention: If didn’t press any keys over three minutes it will auto exit the parameter setting state, to avoid
illegimate operation the controller.
5.1．Parameter setting instruction
Switch Inputs
status
Real time display controller input port state
Remote run: 0 Emergency stop: 0
Remote off: 0 High coolant temp.: 0
Acceleration limit: 0 Low oil pressure: 0
Deceleration limit: 0 High oil temp/Low fuel level.: 0
Attention: Press any menu key will be exit
Relay Outputs
status
Real time display controller output port state
Crank: 0 Fuel: 0
Shutdown : 0 Pre-fuel: 0
Normal: 1 Genset: 0
Acceleration: 0 Deceleration: 0
Attention: Press any menu key will be exit
