- 3 -
Press the key, when the above red LED keep bright, the controller works in “testing”
state. Start the generator in manual, when the generator runs in normal, whatever the
mains supply is normal or not.The controller will automaticly close, onload and keep
running onloading.
(4). State indicator light
Content Function
Indicate the genset failure, protected stop, fault content display in the LCD sreen.
Indicate the genset warning information, alarm detail see screen.
Indicate “remote start” port state, use in monitor the main state generally.
4.2．Connection port define
Port
No.
Function
Power supply 8～36V DC, normal working current <300 mA
1 battery anode input
2 battery cathode input
Analog input（input voltage range 0～5.0V DC）
3
Analog AGND，inside connect with battery cathode.
4 Oil temp./fuel level input
5 Oil pressure input 1
6 Coolant temp. input 1
7 Oil pressure input 2
8 Coolant temp. input 2
9 User-defined sensor
Main three phase voltage input (0-300VAC，insulation inside)
10 Mains voltage phaseR
11 Mains voltage phase S
12 Mains voltage phaseT
13 Mains zero line N
Three phase load current input（ 0-5A AC, without inside isolation， must add current
transformer）
14、15
A phase load current
16、17
B phase load current
18、19
C phase load current
Three phase genset voltage input（0-300V AC, voltage transformer with inside isolation）
20 U phase genset voltage
21 V phase genset voltage
22 W phase genset voltage
23 Zero line N
Relay output port(Relay insulated, contact capability 10A/250VAC/30VDC)
24
25
Emergency supply (Genset supply)
26
27
Normal supply (Mains supply)
Electronic governor Mechanical speed control
28 Idle NC (normal closed) Battery negative
