Mindeo MP8608 - Page 81

75
OR
%8014H4142%
Testing barcode:
Multiple characters C3 replacement: By setting, a number of defined characters in the data string can be
replaced by other defined characters. The maximum number of characters to replace is 11.
Example: Replace all the “A” character in a data string with “B” character; replace “C” with “D”; replace
“E” with “F”.
Original code data
“1 2 3 A 4 C 5 6 E 7 8”
Output code data
“1 2 3 B 4 D 5 6 F 7 8”
Steps: scan the following barcodes in order. The ASCII value for “A” is 41, for “B” is 42, for “C” is 43, for
“D” is “44”, for “E” is 45, and for “F” is 46.
OR
%8016H414243444546%
Testing barcode:
