Mindray MX8

To Next Page

To Previous Page

Part II General Information

Field Replaceable Unit 162

4.2 Assembly Explosive View

4.2.1 Monitor Assembly (A0)

No. Order Number Part Name Qty. Remark

115-067739-00 LCD Assembly( Gray/FRU) 1 Include Wi-Fi and 4G module antenna

115-067740-00 LCD Assembly(Blue/FRU) 1 Include Wi-Fi and 4G module antenna
