Service Manual Combics
Interface Description
Junction box; open.
1.1 Cable to load cell 1
2.1 Cable to load cell 2
3.1 Cable to load cell 3
4.1 Cable to load cell 4
5.1 Connecting cable for A/D
converter / indicator
Pin Assignments in the Junction Box 1
2.1
1.1
5.1
4.1
3.1
2.1
Contacts to connect
the cable 5.1
