165
Item Function No. Number Contents
External control input INPUT7
operation setting
70 66
It is optional as well as F-60
External control input INPUT8
operation setting
70 67
It is optional as well as F-60.
External control input INPUT9
operation setting
70 68
It is optional as well as F-60.
External control output
OUTPUT1 operation setting
70 70
00 : OFF, 01 : Stable,
02 : During canceling the Tare weight
03 : Display of Gross, 04 : Display of Net
05 : Center zero, 06 : During the hold,
07 : Error, 08 : Abnormal weight,
09 : Measuring sequence error, 10 : Z-Band,
11 : OK (S0), 12 : Full flow (S1)
13 : Medium flow (S2), 14 : Dribble flow (S3)
15 : Over (S4), 16 : Under, 17 : Full,
18 : During weighing, 19 : Finish weighing
20 : Discharge (between the discharge gate)
21 : Finish Discharge(between the discharge
gate)
22 : RUN
Eternal control output
OUTPUT2 operation setting
70 71
It is optional as well as F-70
Eternal control output
OUTPUT3 operation setting
70 72
It is optional as well as F-70
Eternal control output
OUTPUT4 operation setting
70 73
It is optional as well as F-70
Eternal control output
OUTPUT5 operation setting
70 74
It is optional as well as F-70
Eternal control output
OUTPUT6 operation setting
70 75
It is optional as well as F-70
Eternal control output
OUTPUT7 operation setting
70 76
It is optional as well as F-70
Eternal control output
OUTPUT8 operation setting
70 77
It is optional as well as F-70
Eternal control output
OUTPUT9 operation setting
70 78
It is optional as well as F-70
Eternal control output
OUTPUT10 operation setting
70 79
It is optional as well as F-70
Eternal control output
OUTPUT11 operation setting
70 80
It is optional as well as F-70
Eternal control output
OUTPUT12 operation setting
70 81
It is optional as well as F-70
Eternal control output
OUTPUT13 operation setting
70 82
It is optional as well as F-70
CC-Link Occupied stations
70 84
0 : 1 station occupied, 1 : 2 station occupied,
2 : 4 station occupied
CC-Link Setting the station
number
70 85
When F-84=0, 01 ~ 64
When F-84=1, 01 ~ 63
When F-84=2, 01 ~ 61
CC-Link Setting baud rate
70 86
0 : 156 kbps, 1 : 625 kbps, 2 : 2.5 Mbps,
3 : 5 Mbps, 4 : 10 Mbps
CC-Link 32 bits date format
70 87
0 : Standard binary format
1 : At minus, The most significant digit is fixed to
[8].
Montanans days
70 90
Do not use here
Montanans No.
70 91
Do not use here
Please change [7*] of above mentioned command to [8*] about the command at the time of
writing.
