(2) Case 4-wire type connection cable
・ As using the 4-wire cable, shorten the load cell terminals A - F and C - G with the attached short bar.
CSD-903 does not work in normal operation when the terminal F and G is in the open status.
・ When the length of CAB-502 (our standard cable) is more than 30 m totally, there may have the case
that the accuracy is out of warranty due to the resistance of cable, the input voltage of the
instrument will be decreased.
