III
(2) Installing the Instrument
Caution
Please secure and set up the spaces between CSD-903 and the devices.
Followings are the dimensions of the Instrument and for environmental spaces required:
Front Side
Rear dimension Panel cut
unit: mm
The side view when BCD connector is installed. (The I/O connector for external control attached is
the same dimension as a BCD connector.)
unit: mm
Control I/O Connector
BCD out connector (Option)
To Next Page
