59
(3) Hold of CC-Link interface
Whether valid or invalid of holding operation of output data by optional CC-Link interface is selected
by the setting of 10
3
digit of F-18. Default is set to [Invalid].
The holding target when the setting of occupied station for CC-Link interface is selected by 4 stations
is [Gross value] and [Net value].
The holding target in the selection of 2 or 1 station(s) is [Display value (Net value /Gross Value)].
The data of holding target retains holding condition even if the error of [OL] or [OVF] occurs in the
holding operation of CC-Link interface. However, the occurrence of [OL] or [OVF] error can be detected
by the signal of [Abnormal weight].
(4) Hold of 2 wires method serial interface
Whether valid or invalid of holding operation of output data by 2-wires method serial interface is
selected by the setting of 10
4
digit of F-18.
Default is set to [Invalid].
Holding target is [Gross value], [Net value], [Tare weight cancellation value], [Gross value condition],
[Net value condition], [Tare weight canceling condition], [Stable condition], [Center zero condition]
and [Fired tare weight condition].
The data of holding target retains holding condition even if the error of [OL] or [OVF] occurs in the
holding operation of 2-wires method serial interface. However, the occurrence of [OL] and [OVF] error
can be detected by the signal of [OVR].
8-10. Sub display section
The value displayed at sub display section is selected.
8-10-1. Select the display of sub display section
The value displayed at sub display section is selected by function F-19.
Setting range: 0 to 20
0 : OFF
1 : A
Brand (1 digit) / Accumulation times (6 digits) / Accumulation value (8 digits)
2 : B
Brand (1 digit) / Accumulation times (6 digits) / Last accumulated data (6 digits)
3 : C
Brand (1 digit) / Last accumulated data (6 digits) / Accumulation value (8 digits)
4 : D
Brand (1 digit) / Last accumulated data (6 digits) / OK (6 digits)
5 : E
Brand (1 digit) / Accumulation times (6 digits) / OK (6 digits)
6 : F
Brand (1 digit) / OK (6 digits) / Accumulation value (8 digits)
7 : G
Brand (1 digit) / Near zero (6 digits) / Full (6 digits)
8 :
OK (6 digits) / Over (5 digits) / Under (5 digits)
9 : I
Brand (1 digit) / OK (6 digits) / Free fall (6 digits)
10 : J
Brand (1 digit) / S1 (6 digits) / S2 (6 digits)
11 : K
Brand (1 digit) / S1 (6 digits) / S3 (6 digits)
12 : L
Brand (1 digit) / S1 (6 digits) / S4 (6 digits)
13 : M
Brand (1 digit) / S2 (6 digits) / S3 (6 digits)
14 : N
Brand (1 digit) / S2 (6 digits) / S4 (6 digits)
15 : O
Brand (1 digit) / S3 (6 digits) / S4 (6 digits)
16 : P
Brand (1 digit) / OK (6 digits)
17 : Q
Brand (1 digit) / Over (5 digits) / Under (5 digits)
18 : R
Brand (1 digit) / Accumulation times (6 digits)
19 : S
Brand (1 digit) / Accumulation value (10 digits)
20 : T
Brand (1 digit) / Last accumulated data (6 digits)
Default is set to [0: OFF].
