8-14-2. Setting method of the external control output
The operation of the external control output is selected by setting function F-70 to F-82.
Setting range: 00 ~ 22
0 : OFF No setting
1 : STABLE Output during stable.
2 : DURING TARE Output when the tare weight cancellation is executed.
3 : GROSS DISPLAY Output when the display is the gross value.
4 : NET DISPLAY Output when the display is the net value.
5 : CENTER OF ZERO Output in the condition of the center zero.
6 : DURING HOLD Output during the holding operation is made.
7 : ERROR Output when the error is occurred.
8 : ABNORMAL WEIGHT Output when display is OL
9 : WEIGHING Sequence ERROR Output when the sequence error is caused.
10 : NEAR ZERO Output in near zero.
11 : OK/S0 When the judgment condition becomes ok in sequential mode.
Also when an output signal S0 is ‘ON’ status in 1 or 2 of comparator
mode.
12 : F.FLOW/S1 When a output signal of full flow is [ON] status in sequential mode.
Also when an output signal S1 is [ON] status in 1 or 2 of comparator
mode.
13 : M.FLOW/S2 When a output signal of medium flow is [ON] status in the
sequential mode. Also when an output signal S2 is [ON] status in 1
or 2 of comparator mode.
14 : D.FLOW/S3 When a output signal of dribble flow is [ON] status in the sequential
mode. Also when an output signal S3 is [ON] status in 1 or 2 of
comparator mode.
15 : OVER/S4 When the judgment condition becomes over in sequential mode.
Also when an output signal S4 is [ON] status in 1 or 2 of comparator
mode.
16 : UNDER When the judgment condition becomes under in sequential mode.
17 : FULL When the judgment condition becomes full in sequential mode.
18 : During measuring Output during measuring.
19 : BATCH FINISH Output in finishing the measurement.
20 : DISCHARGE (GATE OPEN) Output in executing the discharge.
21 : DISCHARGE FINISH Output in the finish of discharge.
22 : RUN Output during measuring mode.
Default is set to [OFF].
8-15. Memory clear
Memory clear is executed by function F-99.
The setting content of the function is returned to the default setting.
When the key is pressed with displayed, becomes a blinking
display.
At this time, please press the key to discontinue a clear memory.
It becomes a stand-by mode, and a clear memory is not executed.
When is a blinking display, the display section is turned off by pressing the key,
and it becomes display, the operation of memory clear is completed.
Please do not clear the memory under the measurement to cause an unexpected malfunction.
