Depth Gauge
The Depth Gauge indicates the approximate depth of a
detected target�
The Depth Gauge is a guide only� Fewer arrows indicate a
shallower target, more arrows indicate a deeper target� The
accuracy can vary depending on the target type and ground
conditions�
After a target is detected, the Depth Gauge will remain on the
LCD for up to 5 seconds, or until the next target is detected�
When there is no detection, the Depth Gauge icon and arrows
are turned off�
Here is an example of the Depth Gauge reading and the
approximate target depth for a US quarter�
50mm
2"
100mm
4"
150mm
6"
200mm
8"
>200mm
>8"

Minelab VANQUISH 440 Specifications

General

Technology	Multi-IQ
Discrimination Segments	12
Audio Tones	3
Iron Bias	High
Sensitivity	10 levels
Volume	10 levels
Display	LCD
Backlight	No
Pinpoint Mode	Yes
Coil Type	Double-D
Search Modes	Coin, Jewelry
Battery	4 x AA
Water Resistance	Coil waterproof to 1 m (3.3 ft)
Audio Output	Built-in speaker and 3.5mm (1/8") headphone jack
Coil Size	10" x 7"
Searchcoil	10x7” DD
Length	Adjustable (1.1m - 1.3m)
