minkaAire F539 - Finishing the Installation; Final Assembly Steps

Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other
one half a turn from the screw head.
Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy
over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section
of the key holes. (Fig. 17)
Step 3. Align the circular hole on canopy with the remaining hole on the hanger bracket, secure
by tightening the two set screws.
Note: Adjust the canopy screws as necessary until the canopy are snug.
FINISHING THE INSTALLATION
7
Fig.17
HANGER
BRACKET
OUTLET
BOX
HANGER
BALL
CANOPY
