8
Step 1. Attach the fan blade to the blade bracket using the screws
provided. Tighten screws securely. Repeat for remaining blades.
(Fig. 18).
Step 2. Remove the rubber stops from the motor and discard.
Rotate the motor so that the screw holes are revealed through
the opening from the switch cup plate. Align holes in blade
bracket and motor and secure with proper screws and fiber
washers provided. Repeat process with the other blade brackets.
(Fig. 19).
ATTACHING THE FAN BLADES
Fig.18 Fig.19
BLADE BRACKET
FAN BLADE
SCREW
FIBER WASHER
FAN BLADE
SCREW
FAN
