12
BATTERY & WIRING INSTALLATION
Advice Regarding Batteries:
Never connect the (+) and the (–) terminals of the battery together. Take care
that no metal object can fall onto the battery and short the terminals. This would
immediately lead to a short and utmost fire danger.
Recommendation:
Use battery boxes and covered battery terminal clamps like Minn Kota accessory
#MK-BC-1.
How to Connect the Batteries
12 Volt Systems:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Connect positive ( + ) red lead to positive ( + ) battery terminal.
3. Connect negative ( – ) black lead to negative ( – ) battery terminal.
4. For safety reasons do not switch the motor on until the propeller is in the water.
24 Volt Systems:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring diagram,
to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of battery 1 and
to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red lead to positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black lead to negative ( – ) terminal of battery 1.
