minnkotamotors.com
5
We recommend that you have another person help with this procedure.
1. Place the mount and motor in position on the deck of the boat.
• We recommend that the motor be mounted as close to the boats
centerline as possible
• Make sure the bow area under the chosen location is clear and
unobstructed for drilling
• Make sure the mount is positioned far enough beyond the edge of the boat.
The motor, as it is lowered into the water or raised into the boat, must not
encounter any obstructions.
2. Once in position, mark a minimum of four of the six mounting holes.
Drill through the marked holes using a 9/32 drill bit.
Note: The four front mounting holes uses the same bolt pattern as used
on Minn Kota quick release plates MKA-21, RTA-17, MKA-16-02 and
MKA-32. The pontoon mount may be attached to any of these for your
mounting convenience.
3. Mount the plate to the bow through the drilled holes using the 1/4”-20 x 2” bolts,
washers and nuts provided.
MOUNT INSTALLATION
