8
Tilt Twist Tiller
These motors offer a choice of five forward and three reverse speeds.
The speed control may be operated in either direction, forward or reverse. Turn the
tilt twist tiller handler counterclockwise from O (off) to increase reverse speed and
clockwise from O (off) to increase forward speed. Thrust decreases as you approach O
from either direction.
The twist grip tiller handle is shipped in
the down position. Firmly pull the handle
up to the horizontal position. The handle
has five available positions: 45° down,
horizontal, 15°, 30° and 45° tilted
up. The handle locks in the horizontal
position, but can be tilted down by
pushing the release button located on
the left underside of the handle pivot.
USING YOUR EDGE
Handle Controls Off/On, Steering
and Forward/Reverse
Release Button

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MINN KOTA EDGE and is the answer not in the manual?

MINN KOTA EDGE Specifications

General IconGeneral
Thrust45 lbs
Shaft Length36 inches
Voltage12V
Battery IndicatorYes
Speed Settings5
