Assembly Part # Description Notes Quantity
B 2770243 CVR KIT, ADV GPS NAV, RT TRV *GPS COVER & DECALS ONLY* 1
Y 2774109 CONTROLLER, ADV GPS NAV, RT PD *GPS RECEIVER* 1
D 2996300 TIE WRAP ASM, 60" 1
Item Part # Description Notes Quantity
2 2031522 COLLAR DRIVE (W/INSERT) 1
4 2011366 SCREW-COLLAR/NEW KNOB(SS) *SALTWATER* 1
6 2292506 CONTROL BOX A/P RT-WHITE *SALTWATER* 1
8 2224707 PLUG, SCREW-DOWN, WHT 1
10 2372103 SCREW-#6 X .375 PLASTITE SS 2
12 2305402 SHRINK TUBE-.374 OD X 2.25" *SALTWATER* 2
14 2263406 SCREW-#10-24 X 2" S/S PPH 1
16 2333101 NUT-HEX #10-24 UNC-2B NYL SS *SALTWATER* 1
18 2372100 SCREW-#8-18 X 5/8 THD* (SS) 4
20 2290213 COVER, CTRL BOX RT PD PRINTED *GPS* 1
22
2395593 DECAL, PUSH BTN TOP, SW, GENERIC 1
2395578 DECAL, PUSH BUTTON TOP, 55 lb, PD, SW *GPS* 1
2395579 DECAL, PUSH BUTTON TOP, 70 lb, PD, SW *GPS* 1
24 2390802 LANYARD W/CARABINR,IP RMT *GPS* 1
26 411690-1 IPILOT 4.0 REMOTE *GPS* 1
28 2256300 TIE WRAP - 5.5" BLACK *70LB* 1
30 2395529 DECAL, DOMED iP LNK 4.0 SW *GPS* 1
p
2397110 MANUAL, IPILOT 4.0 *GPS* 1
p
2397115 GUIDE-QCK REFERENCE IP 4.0 *GPS* 1
p
2015800 HANG TAG "CAUTION... TILT HINGE" 1
p
2317127 INSTRC-INSTALL, RT PD SW 1
p
2297165 MANUAL, DISCLAIMER, DOWNLOAD INFO 1
p
2317125 MANUAL, RT POWERDRIVE SW 1
32 2206301 TIE WRAP, LOW PROFILE 1
34 2997175 REMOTE ASM, MICRO REMOTE 1
36 2206302 TIE WRAP, SCREW MOUNT 6.3” 1
38 2203441 SCREW-#6 X ½” THRD FORM,SSTL 1
40 490380-1 CABLE, ETHERNET PIGTAIL-700 HD *GPS* 1
42 490384-4 CABLE ETHERNET (M12-M12), 30' *GPS* 1
p
2394912 QCK REF.GUIDE, iP MICRO RMT BT *GPS* *MICRO* 1
Control Head Parts List
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
minnkotamotors.com | 41
©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
