Assembly Part # Description Notes Quantity
W 2097091 MTR ASY 12V 3.62 VS 55# *SALTWATER* 1
U 1378131 PROP IND 2091160 (WDLS WDGII) 1
CC 2888460 SEAL & O-RING KIT *3.625* 1
DD 1378126 PROP IND 2061125 WDLS WDG *NOT INCLUDED FROM THE FACTORY* 1
Item Part # Description Notes Quantity
54 421-336 HSG BRUSH END 3.62 WHITE *SALTWATER* 1
56 2002001 TUBE COMPOSITE 54" RT/SP-WHT *55LB* *54"* 1
58 2301555 COLLAR-LATCH, PD/AP 1
60 2303434 SCREW-#8-32 X 5/8 MACH PHCR SS 1
62 2303112 NUT-#8-32 NYLOCK SS 1
64 2031522 COLLAR DRIVE (W/INSERT) 1
68 2011366 SCREW-COLLAR/NEW KNOB(SS) *SALTWATER* 1
70 2092600 PIN-DRIVE 1.06" LG (SS) 1
72 2151726 WASHER-5/16 STD (S/S) 1
74 2053101 NUT-PROP,NYLOC (MED) 5/16 SS 1
76 2091170 PROP-PWR (3 5/8") REAMED 1
78 92-100-117 ARM ASY 12V 3.62 55#2.88" 1
80 140-010 BALL BEARING 1
82 788-015 RETAINING RING 1
84 92-200-302 CTR HSG ASY 3.6 MAGNETIZED 1
86 92-400-337 PLAIN END HSG ASY 3.6 TX/W 1
88 144-049 BEARING - FLANGE (SERVICE ONLY) 1
90 880-003 SEAL 1
92 880-006 SEAL WITH SHIELD 1
94 188-036 BRUSH ASSEMBLY 3.625 55# 2
96 738-036 BRUSH PLATE WITH HOLDER 3.625 1
98 975-040 SPRING-TORSION 2
100 701-081 O-RING 1
102 701-008 O-RING *THRU BOLT* 2
104 337-036 GASKET 1
106 830-007 SCREW, # 8-32 2
108 830-142 THRU BOLT 10-32 X 8.83 *55LB* 2
110 990-067 WASHER - STEEL THRUST 1
112 990-070 WASHER - NYLATRON 2
p Not shown on Parts Diagram.
✖
This part is included in an assembly and cannot be ordered individually.
44 | minnkotamotors.com
©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
12 Volt 3.625" 55lb Motor Parts List
