Assembly Part # Description Notes Quantity
Q 2096069 MTR ASY 24V 3.62 VS 70#SW *SALTWATER* 1
U 1378131 PROP IND 2091160 (WDLS WDGII) 1
CC 2888460 SEAL & O-RING KIT *3.625* 1
DD 1378126 PROP IND 2061125 WDLS WDG *NOT INCLUDED FROM THE FACTORY* 1
Item Part # Description Notes Quantity
130 421-336 HSG BRUSH END 3.62 WHITE *SALTWATER* 1
132 2002001 TUBE COMPOSITE 54" RT/SP-WHT *SALTWATER* 1
134 2301555 COLLAR-LATCH, PD/AP 1
136 2303434 SCREW-#8-32 X 5/8 MACH PHCR SS 1
138 2303112 NUT-#8-32 NYLOCK SS 1
140 2031522 COLLAR DRIVE (W/INSERT) 1
144 2011366 SCREW-COLLAR/NEW KNOB(SS) *SALTWATER* 1
146 2092600 PIN-DRIVE 1.06" LG (SS) 1
148 2151726 WASHER-5/16 STD (S/S) 1
150 2053101 NUT-PROP,NYLOC (MED) 5/16 SS 1
152 2091170 PROP-PWR (3 5/8") REAMED 1
154 92-100-128 ARM ASSY 24V 3.62 70# 1
156 140-010 BALL BEARING 1
158 788-015 RETAINING RING 1
160 92-200-307 CTR HSG ASM 3.6" SW MAGNETIZED 1
162 92-400-337 PLAIN END HSG ASY 3.6 TX/W 1
164 144-049 BEARING - FLANGE *SERVICE ONLY* 1
166 880-003 SEAL 1
168 880-006 SEAL WITH SHIELD 1
170 188-038 BRUSH ASSEMBLY 3.625 70# 6H3 2
172 9-738-038 BRUSH PLATE WITH HOLDER 3.625, #70 LOWER UNIT 1
174 975-042 SPRING-TORSION 2
176 701-081 O-RING 1
178 701-008 O-RING THRU BOLT *THRU BOLT* 2
180 337-036 GASKET 1
182 830-007 SCREW, # 8-32 2
184 830-108 THRU BOLT 10-32 x 9.205 70LB 2
186 990-067 WASHER - STEEL THRUST 1
188 990-070 WASHER - NYLATRON 2
190 2307314 BEAD-FERRITE 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
minnkotamotors.com | 47
©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
24 Volt 3.625" 70lb Motor Parts List
