In the U.S.A., replacement parts may be ordered directly from MINN KOTA Parts Dept., 121 Power Drive,P.O. Box 8129 Mankato,
Minnesota 56002-8129. In Canada, parts may be ordered from any of the Canadian Authorized Service Centers shown on the enclosed
list. Be sure to provide the
model and serial numbers of your motor when ordering parts. Please use the correct part numbers from the parts
list. Payment for any parts ordered from the MINN KOTA parts department, may be by cash, personal check, Discover Card, MasterCard or
VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.
* This item is part of an assembly. This item cannot be sold separately due to machining and /or assembly that is required.
PARTS LIST
Item P/N Description Qty Item P/N Description Qty
1 2777091 36V Motor 60” SW w/tube 1
5 2-100-245 Armature assembly 1
10 140-014 Bearing 1
15 788-040 Retaining ring 1
20 Center hsg. w/tube [Included in #200]
25 2-300-151 Brush end housing assembly 1
30 421-241 Plain end housing assembly SW 1
35 144-017 Flange bearing 1
40 880-025 Seal 2
41 725-095 Paper tube - seal bore 1
50 188-095 Brush 2
60 9-738-011 Brush plate assembly 1
65 975-045 Brush spring 2
n 2881450 Seal & Oring Kit [includes 40, 70-80]
70 701-098 O-ring, plain end 1
71 701-046 O-ring, brush end 1
80 701-009 O-ring, thru-bolt 2
85 2053410 Screw, 10-32 x 1/2” 2
90 830-094 Thru-bolt 12-24 2
95 990-051 Washer, steel 2
100 990-052 Washer, nylatron 2
110 2777312 Ferrite bead w/shrink 1
115 992-011 Washer, belleville 2
120 990-011 Washer, shim 1
125 582-016 Clip, retaining, sonar 1
135 640-044 Leadwire, black 60” 1
136 640-144 Leadwire, red 60” 1
200 2777345 Tube, comp. 60” SW [includes 20] 1
210 2325666 Decal, cover 2
215 2325690 Decal, ctrl box cover, RT Autopilot 1
220 2320201 Cover, ctrl box 1
225 2324032 Ctrl board, compass, Autpillot only 1
230 2302960 Grommet, compass, Autopilot only 3
235 2305415 Wire insulator 2
245 2372100 Screw, 8-18 x .625 3
250 2052510 Cable clamp 3
255 2322501 Control box 1
260 2332102 Screw, 10-24 1
265 2372100 Screw, 8-18 x .625 4
270 2333101 Nut, 10-24 1
275 2224702 Plug, ctrl box 1
305 2771500 Depth collar assembly 1
315 2260906 Knob [included in #305] 1
320 2321706 Washer [included in #305] 1
321 2323102 Nut [included in #305] 1
325 2997028 Steering hsg. asy. [includes 330-500] 1
330 2326502 Steering housing top 1
335 2324604 O-ring, case seal 1
345 2302605 Roll pin 5/16 4
350 2308601 Breather, filter 1
360 2302240 Pinion gear 1
365 2300265 Cap, motor, plastic 1
n 2777024 Dual steering motor assembly, 36V
370 2777025 Motor, steering, 36V 1
380 2302255 Gear, cluster 3rd stage 1
385 2302250 Gear, cluster 2nd stage 1
390 2302245 Gear, cluster 1st stage 1
395 2302610 Shaft, gear 1st stage 1
400 2302620 Shaft, gear 3rd stage 1
405 2302615 Shaft, gear 2nd stage 1
410 2321704 Washer, thrust 2
415 2321515 Liner, output tube 2
420 2324608 O-ring, 224 2
425 2321720 Shim, O-ring 2
430 2327315 Bushing, Aluminum Spacer 2
435 2322200 Gear, output 1
440 2327314 Bushing, Pro Steering SW 2
445 2322031 Tube, output machined 1
450 2321510 Collar, drive, bottom 1
455 2326507 Steering housing, Bottom 1
460 2320605 Leadwire, Steering 1
465 2322601 Pin, latch, SS 1
470 2322603 Pin, pivot, SS 1
475 2327310 Bushing, pivot pin 2
480 2321702 Washer, flat .375 2
485 2263011 E-ring .375 2
490 2322702 Spring, latch pin 2
495 2323410 Screw, 8-32 x .75 1
500 2323408 Screw, 8-32 x 2 7
510 2090651 Leawire, 10 ga 1
515 2305403 Shrink tube, .5 ID x 1.0 Adhesive 4
520 2305410 Shrink tube, .315 OD x 2.25” 3
521 2305415 Shrink tube, .472 OD x 2.25” 1
525 2991271 Coil cord, 60” 1
530 2320202 Cap, dust, coil cord, non-AP only 1
535 2325643 Decal, sideplate, left 1
540 2323405 Screw, 1/4-20 4
545 2321916 Sideplate, left 1
550 2323403 Screw, 1/4-20 x .375 SS 2
555 2321927 Skid, left 1
560 2323422 Screw, 10-24 x .375 2
565 2321700 Washer, #10 SS 2
570 2322921 Stand-off, aluminum anodized 2
571 2323405 Screw 1/4-20 x 1/2” MCH SS 2
575 2323907 Ramp, 4.5” left 1
580 2325117 Pad, rubber rest 4
585 2321706 Washer, #8 4
590 2323412 Screw, 8-18 x .25 4
595 2324706 Insert, ramp 2
600 2994203 Arm, release, left 1
