7.3 Squeegee Caster Adjustment
Washers may be
rearranged to change the
height of the squeegee
caster.
Washers may be
rearranged to change the
height of the squeegee
caster.
Note: When adjusting the wheel height, there should always be 5
washers on each wheel assembly in order fully tighten bolts. Move
washers from the top to the bottom of the bracket or visa versa when
making adjustments. See following page.
