Minuteman ER26 - 12.1 Electric Brake Disk

12.1 Electric Brake Disk
Electric Brake Adjustment
The brake disk, named plastic rotor must be changed when it reaches 50% wear.
(When new, the rotor has a thickness of 2+2 mm; must be changed when it reaches to 1+1 mm
thickness.)
Page 47
Note:
The electric brake will work at 70%of battery power (25.2 volts) and at 70°-80°C (158-176°F)
electric brake working temperature. It shouldn’t exceed an air gap of maximum gap of 0.45-
0.5 mm to work properly at this temperature.
When operated at 100% battery power and at room temperature, the maximum air gap limit
should not exceed 0.7mm.
