OPERATION
Adjusting the Temperature
The temperature is controlled by rotating the temperature selector knob (see below).
For safety reasons, the temperature is limited by an override stop. To obtain a
higher temperature, press the override button on the temperature selector knob and
continue to rotate the knob.
Adjusting the Flow
The ow is controlled by rotating the ow selector knob (see below).
To reduce the amount of water used each time you shower, you can select the ECO
setting.
If you choose a higher ow rate, press the override button on the ow selector knob
and continue to turn the knob.
ON / Increase
Flow
Temperature
Override
Button
Temperature
Selector Knob
OFF / Decrease Flow
Flow Selector Knob
Decrease
Temperature
Increase
Temperature
Eco Setting
Flow Override Button
Eco

Mira CODA PRO Specifications

General

Enclosure Rating	IP65
Weight	300g
Measurement Range	0 - 100%
Operating Humidity	0-95% RH (non-condensing)
Output	4-20 mA
