Mira CODA PRO User Manual

9
INSTALLATION
Suitable Plumbing Systems
Gravity Fed:
The thermostatic mixer must be fed from a cold water cistern (usually tted in the
loft space) and a hot water cylinder (usually tted in the airing cupboard) providing
nominally equal pressures.
Gas Heated System:
The thermostatic mixer can be installed with a combination boiler.
Unvented Mains Pressure System:
The thermostatic mixer can be installed with an unvented, stored hot water
system.
Mains Pressurised Instantaneous Hot Water System:
The thermostatic mixer can be installed with systems of this type with balanced
pressures.
Pumped System:
The thermostatic mixer can be installed with an inlet pump (twin impeller). Refer to
Pump Installation and User Guide for more details.
Ø70 mm
150 mm
107 mm
290 mm
85 mm
DIMENSIONS

Mira CODA PRO Specifications

General

Enclosure Rating	IP65
Weight	300g
Measurement Range	0 - 100%
Operating Humidity	0-95% RH (non-condensing)
Output	4-20 mA
