Mira Gem 88 User Manual

11
1. Gravity fed showers - The shower control MUST be fed from a cold water
storage cistern and hot water cylinder providing nominally equal pressures.
Typical suitable installations
Key to symbols
Drop tight pressure reducing
valve (PRV)
Twin impeller inlet pump
Float operated valve
Stop or servicing valve
Shower control
Warning or overflow pipe
Non-return Valve
Mini expansion vessel
Tempering valve
Gravity Fed Showers

Mira Gem 88 Specifications

General

Product Type	Electric Shower
Mounting	Wall Mounted
Maximum Static Pressure	10 Bar
Material	Plastic
Water Pressure	0.7 bar to 10 bar
Color	White
