4
RAXN-4000LCD
in a BB-1001DR
Class A wiring
Twisted Pair Wiring
RAXN-4000LCD
in a BB-1001DR
Node 5
FX-4003-12N in a UB-1024DS
with a DOX-1024DSR Door
RS-485
Node 4
FX-4009-12N in a BB-5008R
CACF
RS-485
Node 3
FX-4017-12N in a BBX-1072ARDS
RAXN-4000LCD
in a BB-1001DR
RS-485
Node 1
FX-4003-12NXT in a
BBX-1024XTR
Node 2
FX-4003-12N in a UB-1024DS
with a DOX-1024DSR Door
Typical FleX-Net FX- 4000 Wiring Without Audio
