Mircom FleXNet FX-4000 User Manual

84
12.0 FleX-Net™ Mass Notification System (BBX-FXMNS)
Enclosure
This enclosure can accommodate all existing modules, except the QMP-5101N Network
Master Paging Control module and the QMT-5302N Master Firefighters’ Telephone. New
models, QMP-5101NV vertical mounting master paging microphone and QMT-5302NV Master
Telephone panels are used instead to mount within the BBX-FXMNS Enclosure. The BBX-
FXMNS enclosure includes a backbox and a two part door and display deadfront chassis.
Figure 47 BBX-FXMNS Enclosure
Note: When using the BBX-FMNS as a Mass Notification System (ACU) refer to Appendix I.
*/$0.*/(
$"--
$-&"3"--
$0//&$5
."45&35&-
5306#-&
$0..0/5&-
5306#-&
'"/%".1&3
9”
7.6”
20”
62.7”
22.4”
61.1”
