8.2 Common Controls
8.2.1 LCD Display:
The display is a large 4 line by 20 character back-lit alphanumeric LCD. It displays information
on the panel and its devices. There are cursor buttons for menu selection and control.
Information provided by the LCD display is an alarm log, an event log, current levels, device
information, verification and maintenance reports.
8.2.2 Queue Buttons
Use the queue buttons to select a particular queue to review.
Press the Alarm Queue button to cycle through all the unacknowledged alarms. Press
and to cycle through all the alarms, both acknowledged and unacknowledged. Press the
right cursor button to scroll up by 10 events at a time. Press the left cursor button
to scroll down by 10 events at a time.
Press the Supervisory Queue button to cycle through all the unacknowledged supervisory
conditions. Press and to cycle through all supervisory conditions, both
acknowledged and unacknowledged. Press the right cursor button to scroll up by 10
events at a time. Press the left cursor button to scroll down by 10 events at a time.
Press the Trouble Queue button to cycle through all the unacknowledged trouble conditions.
Press and to cycle through all troubles, both acknowledged and unacknowledged.
Press the right cursor button to scroll up by 10 events at a time. Press the left cursor
button to scroll down by 10 events at a time.
Press the Building Queue Button to cycle through all the unacknowledged building (monitor)
conditions. Press and to cycle through all queued monitor conditions, both
acknowledged and unacknowledged. Press the right cursor button to scroll up by 10
events at a time. Press the left cursor button to scroll down by 10 events at a time.
Queues are displayed on the screen according to a priority sequence. Queue priority ranking
from highest to lowest is as follows: alarm, supervisory, trouble, and monitor. If, for example,
you are viewing a monitor queue and an alarm occurs, the display will immediately display the
alarm condition. Also, if there is no activity on the system for 10 seconds after you have
pressed a queue button, the display will switch to the highest priority condition.
