6 Mirka® LEROS Random Orbital Sander • 225 mm (9") • 100–240 V & 110 V
Parts list – kits
Mirka code Item Description Kit Qty Tightening torque
Type label kit 100–240 V A
1 Type label 5
MIW9520311 O-ring kit B
3 O-ring 39.2 x 3.0 3
20 Rubber washer 2
MIW9521011 Handle screw kit C
10 Screws STP 2.5 x 16 mm 7 0.8 Nm
12 Screws 2.5 x 25/10 mm 1 0.8 Nm
19 Screws 3 x 16 mm 9 1.4 Nm
MIW9521111 PCB spacer kit D
11 PCB spacer 8
MIW9521211 PCB screw kit E
12 Screws 2.5 x 25/10 mm 8 0.5 Nm
MIW9521511 Power socket assembly kit F
15 Power socket assembly 1
26 Grounding screw 1 0.8 Nm
27 Star washer M3 1
MIW9521811 Screw kit Y-branch G
18 Screws 3 x 14 mm 6 0.8 Nm
MIW9522511 Dust hose kit H
25 Dust hose 2
MIW9523311 Screw kit fairing I
33 Screws STS T25 x 10 12 0.8 Nm
MIW9523811 Screw kit motor J
38 Lock nut 4 1.4 Nm
41 Screws M3 x 12 mm 4
MIW9524011 Cover cap kit K
40 Screw STS-Plus KN6039 2.5 x 10-T8 2 0.8 Nm
45 Cover cap 1
MIW9514711 Hole screw kit L
47 Hole screws 8 0.8 Nm
MIW9524811 Joint screw kit M
48 Screw caps 2
50 O-ring 4
51 Joint screws M5 ** 4 3 Nm / 5 Nm
MIW9515411 Joint fork kit N
52 Screws M4 x 50 2 1.4 Nm
53 Joint fork 2
54 Lock nut 2
MIW9536011 Screw pad conversion kit O
40 Screw STS-Plus KN6039 2.5 x 10-T8 2 0.8 Nm
43a Backing pad 225 mm (Screw mounting of interface) 1
45 Cover cap 1
46 Interface 1
47 Hole screws 8
MIW9523211 Dynamic weight kit P
32 Screws M5 x 10 1 3 Nm
34 Fan washer 1
36 Dynamic weight 1
** See service instruction for torque.
NOTE! Repairs done by non-authorized repairer will breach the Mirka warranty.
Electrical tool must be serviced by a qualified repair person and in accordance with national requirements.
