19
Bow Trolling Systems
Your MirroCraft boat may be equipped with one of the following trolling
systems:
Deluxe bow trolling panel (Figure T-1): The deluxe panel has the option of
allowing a 12 volt or 24 volt trolling motor to be installed on your boat.
To be used for 24 volts both batteries (A + B) must be connected to the
trolling harness. The plug must be wired for 24 volts according to the
markings on the plug. To be used for 12 volts battery (A) must be con-
nected to the trolling harness and the plug must be wired for 12 volts
according to the markings on the plug.
Figure T-1
