8
Recirc/Timer Kit: This kit consists of a pump, aerator head (Figure B-1) and
timer switch panel (Figure B-2). This switch panel has an inline fuse on the red
wire.
• The panel has three positions on the front of it.
• The recirc kit may be installed on a livewell or on a baitwell depending
on the model and options on the boat you own.
• To use the recirc pump you must first fill the livewell or baitwell with
fresh water. Do this by turning on main livewell or baitwell pump.
When water level reaches the top of standpipe, turn off pump and then
start recirculation pump in the mode that you want. Livewell or baitwell
must be full before starting recirc pump.
On - Turns pump on continuous run
Off - Turns pump off
Off - On - Intermittent operation which typically turns the recirc pump
on and off at three minutes intervals.
Figure B-1
Figure B-2
