MiTAC Maestro 830 - Page 15

21
NC
NC
22
EDID_3.3V
VCC3
23
GND
Ground
24
GND
Ground
25
GND
Ground
26
TCK0P
LVDS Channel A diff data output - positive
27
TCK0N
LVDS Channel A diff data output - negative
28
GND
Ground
29
GND
Ground
30
GND
Ground
31
NC
NC
32
BKLT_EN
33
LVDS_PWM
34
TCK1P
LVDS Channel B diff data output - positive
35
TCK1N
LVDS Channel B diff data output - negative
36
BKLT_PWR
Selectable BKLT power output
37
BKLT_PWR
Selectable BKLT power output
38
BKLT_PWR
Selectable BKLT power output
39
NC
NC
40
NC
NC
T A B L E 10: 40- PI N L V D S D A T A H E A D E R P I N - O U T R E F E R E N C E
