mitoredlight MitoPRO+ Series - MitoPRO+ XL Series Panel Mounting Options; XL Panel Mounting Types; Floor to Wall Mounting Procedure

MEGA
Floor mount (secure to wall
with L bracket), vertical
stand or horizontal stand.
ELITE
Floor mount (secure to
wall with L bracket), or
vertical stand only.
Due to the size and weight of the XL panels they should only be installed as below:
The floor to wall mounting bracket is designed to allow the bottom of the panel to be
rested on the floor and with the top of the panel secured against the wall. This
bracket is not intended to support the weight of the light suspended off the floor!
ULTIMATE
Floor mount (secure to wall
with L bracket) only.
Floor to wall mounting:
Attach the 4 double ended screws to the top of the panel. Place panel up against wall in
the final position it will be mounted in. Install the L bracket by aligning groves and sliding
as shown in the pictures.
WARNING!
MITOPRO+ XL SERIES
20 www.mitoredlight.com
