mitoredlight MitoPRO+ Series - Vertical Stand Bracket Placement Guide; Step 2: Hanging Panel on Stand

fig-1
fig-2
Step 1: Screw the vertical stand mounting brackets to panel as shown (single panel example)
Step 2:
Hang the panel (with vertical
mounting brackets) on the cross
bracket. Then to secure the panels to
the stand, install parts C and D on
each side of the vertical brackets as
shown (fig-4).
** See product specific user manuals / video tutorials for bracket install instructions
as the brackets vary by Series.
https://mitoredlight.com/pages/user-manual
