15
CARBURETTOR
• The carburettor mixture setting has been set at the factory and will not need adjusting.
• Adjusting the idle speed Fig 23. If adjustment is necessary turn the T screw clock wise until the blades
start to move, then turn the screw T anticlockwise until the blades stop.
Fig 23 T screw
• If the idle speed cannot be adjusted to stop the cutting head moving at idle, contact your dealer
for repair before use.
Fig 24 SAFETY LOCK,
THROTTLE LEVER
Fig 24 SAFETY LOCK
THROTTLE LEVER
SAFETY LOCK
• The safety lock is to prevent the throttle lever from accidentally being engaged.
• The throttle lever, Fig 24, can only be pressed in if the safety lock is held down.
• Check if the safety lock and throttle lever returns to its original position and the engine returns to idling
when you release your hand from the handle.
• Any defects contact your nearest service agent for repairs before using the machine.
STORAGE
• Remove the spark plug, pour a small amount of oil into the cylinder. Rotate the crankshaft several
times using the starting rope in order to distribute the oil. Put the spark plug back in.
• Remove the fuel from the machine.
,
