Mitox 28MT - Page 40

28MT Multi-Tool
40
Original Instructions Version June 16
28MTa_160616
Parts List - Engine
ID No. Part Number
Description
34 MITBC260D.01.11.01-00 IGNITION COIL
35 MIGB/T2671.2 M5X20 SCREW M5X20
36 MIGB/T119.2 5X10 PIN 5X10
38 MIGB/T2671.2 M5X25 SCREW M5X25
39 MIYD38-3.01.01.02-00 OIL SEAL 12X22X7
40 MITBC260D.01.10.00-00 FLYWHEEL
41 MIGB/T6177.2 M8X1 NUT M8X1
42 MIGJB25D.01.00.00-15 WAVE SPRING WASHER
43 MITBC260D.01.00.03-00 CLUTCH ASSEMBLY
44 MIGJB25D.01.00.00-14 BOLT FOR CLUTCH
45 MIGB/T119.2 4X10 PIN 4X10
46 MITBC261D.01.01.00-4 FAN COVER
47 MIGB/T2671.2 M5X20 SCREW M5X20
48 MITBC260D.01.14.01-00 CLUTCH DRUM ASSEMBLY
49 MIGB/T893.1 35 CIRCLIP (SIZE 35)
50 MIGB/T276 6202 BALL BEARING 6202-2Z
51 MIGB/T894.1 15 STOP RING (SIZE 15)
52 MITBC261D.01.14.00-1 CLUTCH DRUM HOUSING
53 MIGB/T2671.2 M6X20 SCREW M6X20
54 MITBC430D.01.14.00-2 ANTIVIBE RUBBER
55 MITBC430D.01.14.00-4 CLAMP RH
56 MITBC430D.01.14.00-3 CLAMP LH
57 MIGB/T2671.2 M5X25 SCREW M5X25
58 MIGB/T2671.2 M5X12 SCREW M5X12
59 MIGB/T2671.2 M5X52 SCREW M5X52
60 MITBC226D.1-2 MUFFLER COVER
61 MITBC261D.01.09.00-00 MUFFLER
62 MITBC261D.01.00.00-8 GASKET
63 MITBC260D.01.00.00-6 GASKET - MUFFLER
64 MIGB/T2671.2 M4X12 SCREW M4X12
65 MITBC260D.01.00.00-5 GASKET
66 MITBC261D.01.00.01-00 MANIFOLD
