Mitox 28MT - Page 41

28MT Multi-Tool
41
Original Instructions Version June 16
28MTa_160616
Parts List - Engine
ID No. Part Number
Description
67 MITBC431D.01.00.00-12 STRAP
68 MIGB/T845 ST3.5X9.5 ST SCREW 3.5X9.5
69 MIGB/T2671.2 M5X20 SCREW M5X20
70 MITBC261D.01.00.00-4 GASKET / CARBURETTOR
71 MITBC261D.01.06.00-00 CARBURETTOR
72 MITBC261D.01.08.00-00 AIR FILTER ASSEMBLY
74 MIGB/T2671.2 M5X45 SCREW M5X45
75 MITBC261D.01.08.00-3 AIR BOX ASSEMBLY
77 MITBC431D.01.13.01 FUEL CAP ASSY
78 MITBC431D.01.13.01-3 PETROL CAP RUBBER
79 MITBC431D.01.13.01-2 STOPPER
80 MITBC261D.01.13.00-1 FUEL TANK
81 MITBC431D.01.13.00-2 FUEL TANK RUBBER
82 MITBC261D.01.00.00-7 FUEL TANK BRACKET
83 MIGB/T2671.2 M5X25 SCREW M5X25
84 MIYD45.03.04-00 BREATHER ASSY
85 MITBC431D.01.13.00-6 BREATHER PIPE
86 MITBC430D.01.13.00-4 FUEL PIPE
87 MITBC430D.01.13.00-5 RETURN PIPE
88 MITBC431D.01.13.00-3 GROMMET
89 MIYD45.01.01.01-3 CIRCLIP
90 MITD38-3.03.04-00 FUEL FILTER
