435 L/U Brushcutter
30
Original Instructions Version December 12
Specications
MODEL MITOX 435L / 435U
Engine Type Air cooled 4-stroke overhead valve petrol engine
Model 139F-2
Displacement : ( cm3) 33.5 cc
Max. output 0.8 (kw) in accordance with ISO 8893
Idle speed: rpm (min –1) 2800±150
Max rpm 7800
Fuel tank capacity 0.65L
Engine oil capacity 90ml
Fuel Unleaded Petrol
Carburettor Diaphragm type
Spark Plug CMR6A
Transmission Centrifugal clutch, spur gear, cam-crank
Fixation hole diameter: (mm) 25.4
Dry Weight w/o harness & gasoline 7.06kg / 7.16kg
Overall size (LxWxH) 1800mmx380mmx250mm
Reduction ratio 22 :17
Cutting head Cutting
width
3 teeth
blade
255mm
Nylon
head
415mm
3 teeth blade thickness 2.92mm
Cutting line diameter 2.4mm
Max. blade rotation
speed:
7500 rpm (min –1)
Rotation direction Counter Clockwise(as seen from above)
