48
OCH668B
F1 F2 F3 F4
unem ecivreS
rosruC
:unem niaM
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
1
Select "Service" from the Main menu, and press the button.
2
Select "Test run" with the F1 or F2 button, and press the button.
Select "Test run" with the F1
or F2 button, and press the button.
F1 F2 F3 F4
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
F1 F2 F3 F4
Remain
Vane
Cool mode: Checkthecoldairblowsout.
Heat mode: Checktheheatblowsout.
Press the F1
button to go through the operation modes in the order of
"Cool and Heat".
Check the auto vane with the F1
F2 buttons.
Checktheoperationoftheoutdoorunitfan,also.
Press the
button to return to “Test run operation”.
Press the
button.
Whenthetestruniscompleted,the“Testrunmenu”screenwillappear.
Thetestrunwillstopautomaticallyafter2hours.
*Thefunctionisavailableonlyforthemodelwithvanes.
Test run operation
Auto vane check*
Press the button and open the Vane setting screen.
Function buttons
F1 F2 F3 F4
MENU RETURN SELECT ON/OFF
8-1-1-2. Test run for wired remote controller <PAR-31MAA> <PAR-32MAA>
