[ III HBC Controller Components ]
- 68 -
HWE1708A GB
[2] Sub-HBC Components
1. Front
(1) CMB-WM1016V-AB
(2) CMB-WM108V-AB
To Main-HBC (Hot water)
To Main-HBC (Cold water)
From Main-HBC (Cold water)
From Main-HBC (Hot water)
To Main-HBC (Hot water)
To Main-HBC (Cold water)
From Main-HBC (Cold water)
From Main-HBC (Hot water)
