6.11 Monitor Function 6.11.2 Local device monitor/test
6 - 39
6.11.2 Local device monitor/test
This operation is useful for debugging a program, monitoring local devices ( Section 9.14.2) in the program
monitored by GX Developer. íç1
(1) Monitoring a local device
Table6.10 shows the monitor operation when the CPU module executes three programs "A", "B", and "C" and D0
to D99 are set as a local device.
(Three programs are to be executed in the order of A B C (END processing) A B....)
注1
Table6.10 Data displayed when three programs are executed
Setting
Monitordevice
D0(Localdevice) D100(Globaldevice)
When the device is not set as
a local device
D0 in the program "C" is monitored.
D100 after the program "C" is executed is
monitored.
When the device is set as a
local device
D0 in the displayed program is monitored.
D100 after the program "C" is executed is
monitored.
Note6.2
Note6.2
The Q00UJCPU does not support the use of local devices.
