39
4.4.2 Inlet air Temperature Display Setting
The following settings can be made.
1 ON (default) : The inlet air temperature is displayed.
2 OFF : The inlet air temperature is not displayed.
Setting the Inlet Air Temperature
■ Display example
(1) While pressing the
button, press the
button for two seconds to activate the remote controller’s function
selection mode.
(2) Press the
button until
appears on the screen (at A).
[Display A]
(3) Press the
button so that “ROOM TEMP DISP SELECT” appears on the screen (at A).
(4) Press the
button to select “on” or “oFF” on the screen (at D).
[Display D]
(5) While pressing the
button, press the
button for two seconds to return to normal mode.
* If you press the
button before the
button, the settings you have made will be cancelled.
■ Inlet air temperature display example ■ Inlet air temperature display example
when “ON” is selected when “OFF” is selected
CHANGE
LANGUAGE
FUNCTION
SELECTION
MODE
SELECTION
DISP MODE
SETTING
To Next Page
